Zyxel DX3301, WiFi 6 AX1800 VDSL2 IAD 5-port Super Vectoring Gateway (upto 35B) and USB with Easy Mesh Support

• DX3301, WiFi 6 AX1800 VDSL2 IAD 5-port Super Vectoring Gateway (upto 35B) and USB with Easy Mesh Support

• WiFi 6 AX1800 VDSL2 5-port Super Vectoring Gateway (upto 35B) and USB with Easy Mesh Support

• The Zyxel DX3301-T0 provides high-speed internet access with QoS support to meet the worldwide market demand for triple-play services. With the built-in 2x2 802.11ax WLAN function and Zyxel MPro Mesh® Solutions, the Series provides seamless WiFi experience and superior, feature-rich WiFi connectivity for service providers to deliver high-performance internet access services.

• WiFi 6 (11ax) for superior performance and coverage

• Zyxel MPro Mesh® Solutions (compliant with EasyMesh standards)

• Remote management via TR-069 and TR-181 i2

• NAT, firewall with SPI and DoS for better security

• VoIP SIP protocol with 3-way conference calls

• Multiple SSIDs for various service deployment scenarios

• Zyxel-developed OPAL for superior flexibility and faster time-to-market

• Ecofriendly compact design

• WiFi 6 technology for superior lag-free performance

• Supporting the latest WiFi 6 (11ax) standard, the Series offers speeds of up to 1200 Mbps* with 2x2 802.11ax and 574 Mbps* with 2x2 802.11ax. The uplink MU-MIMO, Orthogonal Frequency Division Multiple Access (OFDMA) and beamforming technologies empower the Series to deliver high speed internet for multi-streaming data access and optimal WiFi experience without dead zones.

• Zyxel OPAL firmware achieves superior flexibility and faster time-to-market

• Compliant with the same OPAL firmware trunk applied in all Zyxel CPEs,the Series inherits a rich, field-proven feature set for guaranteed unchanged user experience even after migrating to the new devices.

• Premium MPro Mesh® for whole-home coverage**

• Featuring EasyMesh fully compliant Zyxel MPro Mesh® Solutions, the Series enhances your subscribers’ experience by providing self-adapting, easy-to-manage whole-home WiFi coverage, while reducing your service OPEX.

• Quality of Service (QoS) support

• With QoS features, service providers can freely design their QoS policies and prioritize mission-critical services such as IPTV and VoIP based on their service plan offerings. This improves network efficiency and productivity that enable service providers to offer a real multi-play solution to meet the residential user needs.

• TR-069/TR-181 issue-2 remote management for lower OPEX

• Compliant with TR-069, the Series significantly simplifies deployment complexity and lowers operating and maintenance costs. The additional support to the latest TR-181 issue-2 data model also enhances service providers' visibility on subscriber LAN networks to offer improved customer assistance.

• Ecofriendly compact design

• Zyxel commits to a sustainable future and to improving the environmental well-being of the community. The Zyxel DX3301-T0 adopts foldable stands with an ultra-thin exterior case to shrink each package volume, which improves pallet utilization by approximately 46% for lower carbon emissions.

• Hardware

• WAN interface

• DSL RJ-11/RJ45/GbE

• Ethernet port (10/100/1000)

• 5 (1 for Ethernet WAN)

• POTS FXS port

2

• USB port

• 1 (USB 2.0)

• VDSL

• G.993.1 VDSL

• G.993.2 VDSL2, Band 997, 998, Over POTS

• VDSL profiles: 8a/b/c/d, 12a/b, 17a, and 35b

• G.vector

• ADSL

• G.992.1 (G.dmt)

• G.992.2 (G.lite)

• ANSI T1.413 compliant

• G.992.3 (ADSL2)

• G.992.5 (ADSL2+)

• Supports G.INP

• Router features

• IPv4/IPv6

• NAT

• Port forwarding

• WAN connection types: DHCP, PPPoE

• DHCP option 60/121/125

• DHCP server on LAN

• IGMP v1/v2

• IGMP proxy

• Dynamic DNS

• Wireless

• Auto channel selection

• WiFi Multimedia (WMM)

• Wireless scheduling

• Wireless output power management

• Multiple SSID up to 4

• Wi-Fi Protected Setup (WPS)

• Intra-BSS traffic block

• MAC address filtering

• VLAN

• 802.1q tag/tag based VLAN

• VLAN to ETH port mapping

• Bridged/routed VLAN

• Voice

• SIP v2 (RFC 3261)

• Yes

• SIP account (URL type included)

• Yes

• SDP (RFC 2327)

• Yes

• RTP (RFC 1889)

• Yes

• RTCP (RFC 1890)

• Yes

• G.168 echo cancellation

• Yes

• VAD/CNG

• Yes

• CODEC

• G.711 a/u law /G.726/G.722/G.729

• DTMF detection

• Yes

• DTMF: In-band and out-of-band

• Yes

• QoS (IP bandwidth management)

• Yes

• ToS

• Yes

• Phonebook

• Yes

• FAX, modem detection and pass-through

• Yes

• T.38 FAX

• Yes

• IVR

• Yes

• Call waiting

• Yes

• Call hold/call retrieve

• Yes

• Call transferring

• Yes

• Call forwarding

• Yes

• Caller ID

• Yes

• Do not disturb

• Yes

• Three way conference

• Yes

• Flexible dial plan

• Yes

• Dynamic jitter buffer

• Yes

• On hook, off hook and flash detection

• Yes

• Standards/profile

• VDSL2 Vectoring (up to 35b)/ADSL2+

• WLAN

• 2.4 GHz 2x2 ax + 5 GHz 2x2 ax

• Firewall

• Stateful packet inspection

• Yes

• Denial of service

• Yes

• ICMP blocking

Yes

• Váha: 0.41000 kg
• PartNumber: DX3301-T0-EU01V1F

Parametry produktu

Výrobce:	ZyXEL
Rychlost přenosu Wi-Fi:	433,3Mbps (802.11ac)
Pásmo:	2,4 GHz + 5 GHz dual
Podpora PoE:	Ne
Výrobce:	ZyXEL
Typ:	VDSL
Wi-Fi:	vyšší 802.11n
Rychlost ethernetu:	1 Gbit
VPN:	Ano
Wi-Fi:	Ano
GPSR:	Zyxel Networks A/S;Gladsaxevej 378,2860,Soborg,Denmark;info@cz.zyxel.com
